For example take a length of fiber and measure the optical power through the fiber.

Fiber optic cable coupler loss chart.

Advantages are the low loss easy coupling with the optical fiber transmission line and no polarization dependent loss. Real world fiber optic splitters show uniform performance across the whole spectrum of interest from 1260 to 1600 nm. Star couplers with up to 32 ports have been possible using fused tapered fiber 3 db couplers. Optical splitter loss ratio 1 n.

Optical coupler is an optical device that combines or splits power from optical fibers. Power budgets and loss budgets the terms power budget and loss budget are often confused the power budget refers to the amount of fiber optic cable plant loss that a datalink transmitter to receiver can tolerate in order to operate properly. Note the reading p1. 1 n fiber optic splitter loss ratio chart are given bellow.

Now cut the fiber in half terminate the fibers and connect. In any fiber optic interconnection some loss occurs. Insertion loss for a connector or splice is the difference in power that you see when you insert the device into the system. Sometimes the power budget has both a minimum and maximum value which means it needs at least a minimum value of loss so that it does not overload.

The estimate called a loss budget is calculated using typical component losses for each part of the cable plant.
